| Nombor Bahagian | H220VA01 |
| Jenama | AUO |
| Saiz | 2.2 |
| Permohonan | Mobile Phone |
| Resolusi | 240×320 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 75:19:1 |
| Warna | 262K |
| Lampu latar | 4S1P |
| Antara muka | Parallel |
| pengilang | AUO |
| saiz skrin | 2.2 inch |
| nombor piksel | 240(RGB)×320 (QVGA) 180PPI |
| kawasan aktif (mm) | 33.84 × 45.12 (H×V) |
| kawasan bezel (mm) | 35.4 × 46.92 (H×V) |
| kecerahan | 100 cd/m² (Typ.) |
| sudut pandangan | 47/28/30/80 (Typ.)(CR≥10) |
| pandangan yang baik di | 6 o'clock |
| kedalaman warna | 262K 42% NTSC |
| jisim | - |
| kadar segar semula | - |
| jenis isyarat | Parallel RGB (1 ch, 6-bit) + SPI , 39 pins FPC |
| bekalan voltan | 2.8V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| nama model | H220VA01 |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 40.6 × 56.66 × 3.11 (H×V×D) |
| rawatan | - |
| nisbah kontras | 75 : 1 (Typ.) (TM) 9:1 (Typ.) (RF) |
| tindak balas | 29 (Typ.)(Tr+Td) ms |
| mod kerja | TN, Normally White, Transflective |
| lampu latar | 4S1P WLED , No Driver |
| digunakan untuk | Mobile Phone |
| skrin sentuh | Without |
