| Nombor Bahagian | H027QT01 |
| Jenama | AUO |
| Saiz | 2.7 |
| Permohonan | MPH |
| Resolusi | 208×320 |
| Komposisi | LCM |
| Kecerahan | 60 |
| CR | 50:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | AU Optronics |
| model panel | H027QT01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 2.7 inch |
| resolusi | 208(RGB)×320 |
| mod paparan | TN, Normally White, Transflective |
| kawasan aktif | 36.816×56.64 mm |
| garis besar | 45.8×69.17 mm |
| permukaan | |
| kecerahan | 60 cd/m² (Typ.) |
| nisbah kontras | 50:1 (Typ.)(Transmissive)20:1 (Typ.)(Reflective) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 10/30 (Typ.)(Tr/Td) |
| sudut pandangan | 45/45/45/45 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 2S2PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 60 pins |
| voltan masukan | 3.3/5/5/3.3/12/-12V (Typ.)(DVCC/AVDD/AVDD1/AVDD2/VGH/VGL) |
| permohonan | MPH |
