| Nombor Bahagian | HVA32WV1-D00 |
| Jenama | HYDIS |
| Saiz | 3.2 |
| Permohonan | MPH |
| Resolusi | 480×800 |
| Komposisi | CELL |
| Kecerahan | 0 |
| CR | 600:1 |
| Warna | 16.7M |
| Lampu latar | No B/L |
| Antara muka | |
| jenama panel | HYDIS |
| model panel | HVA32WV1-D00 |
| jenis panel | a-Si TFT-LCD , CELL |
| saiz panel | 3.2 inch |
| resolusi | 480(RGB)×800 , WVGA |
| mod paparan | HFFS, Normally Black, Transmissive |
| kawasan aktif | 41.76×69.6 mm |
| garis besar | 45.36×77.6 mm |
| permukaan | Without Polarizer |
| kedalaman kaca | 0.25+0.25 mm |
| ketransmisian | 3.3% (Typ.)(with Polarizer) |
| nisbah kontras | 600:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193172% |
| masa tindak balas | 33 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| ic pemandu | Suggest LG4572, LG4573 |
| permohonan | MPH |
| ACX567AKM-7 | SONY | 3.2 | 320×480 |
| CMD500TT10-C1 | ORTUSTECH | 3.2 | 320×240 |
| DLC0320DUG | Other | 3.2 | 240×320 |
| ET0320A5DM9 | EDT | 3.2 | 240×320 |
| H320QN01 V2 | AUO | 3.2 | 320×480 |
| HVA32WV1-D00 | HYDIS | 3.2 | 480×800 |
| LH320WV3-SH02 | LG Display | 3.2 | 480×800 |
| LMS320HF46 | Samsung | 3.2 | 240×432 |
| LT032MDQ7000 | JDI | 3.2 | 360×480 |
| TFT2N0369-E | Other | 3.2 | 240×320 |
| AMS300FW01-0 | Samsung | 3.0 | 240×400 |
| AMS395GB01 | Samsung | 4.0 | 360×640 |
| AMS427GL45-0 | Samsung | 4.3 | 480×800 |
| H466TAN02.4 | AUO | 4.7 | 720×1280 |
| LS026Q3DX01 | SHARP | 2.6 | 240×320 |
| LS055R1SX03 | SHARP | 5.5 | 1440×2560 |
| LTP283QV-F03 | Samsung | 2.8 | 240×320 |
| TFT240320-237-E | Other | 2.8 | 240×320 |
| TM020GDZ25 | Tianma | 2.0 | 176×220 |
| TM022HDHT1-00 | Tianma | 2.2 | 240×320 |
