| Nombor Bahagian | TM018FDZ02 |
| Jenama | Tianma |
| Saiz | 1.8 |
| Permohonan | MPH |
| Resolusi | 128×160 |
| Komposisi | LCM |
| Kecerahan | 190 |
| CR | 250:1 |
| Warna | 65K/262K |
| Lampu latar | WLED |
| Antara muka | SPI |
| jenama panel | TIANMA |
| model panel | TM018FDZ02 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 1.8 inch |
| resolusi | 128(RGB)×160 |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 28.032×35.04 mm |
| garis besar | 34×45.83×2.85 mm |
| permukaan | |
| kecerahan | 190 cd/m² (Typ.) |
| nisbah kontras | 250:1 (Typ.) |
| warna paparan | 65K/262K , CIE193158% |
| masa tindak balas | 15/35 (Typ.)(Tr/Td) |
| sudut pandangan | 65/65/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 1S2PWLEDWithout Driver |
| antara muka isyarat | SPI, 14 pins |
| voltan masukan | 2.8/2.8V (Typ.)(VDDI/VDD) |
| permohonan | MPH |
