| Nombor Bahagian | G101EVN01.0 |
| Jenama | AUO |
| Saiz | 10.1 |
| Permohonan | IA |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 1300:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | AUO |
| model panel | G101EVN01.0 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.1 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mod paparan | MVA, Normally Black, Transmissive |
| kawasan aktif | 216.96×135.6 mm |
| garis besar | 229.46×149.2×5.54 mm |
| permukaan | Hard coating (3H), Reflection 1.5% (Max.) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 1300:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193145% |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (1 ch, 6-bit), 40 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | IA |
| G101EVN01.0 | AUO | 10.1 | 1280×800 |
| G101EVN01.3 | AUO | 10.1 | 1280×800 |
| HSD101PFW1-B00 | HannStar | 10.1 | 1024×576 |
| HV101WU1-1E3 | HYDIS | 10.1 | 1920×1200 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| LQ101R1SX01A | SHARP | 10.1 | 2560×1600 |
| LTN101NT05-U03 | Samsung | 10.1 | 1024×600 |
| M101MWW4 R0 | IVO | 10.1 | 1024×600 |
| N101ICE-G63 | Innolux | 10.1 | 1280×800 |
| N101L6-L0C | Innolux | 10.1 | 1024×600 |
| AA065VB01 | Mitsubishi | 6.5 | 640×480 |
| AA104VB04 | Mitsubishi | 10.4 | 640×480 |
| AA104XD12--G1 | Mitsubishi | 10.4 | 1024×768 |
| COM70T7M07ZLC | ORTUSTECH | 7.0 | 800×480 |
| G104XGE-L05 | Innolux | 10.4 | 1024×768 |
| KCG057QV1DB-G500 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G020 | Kyocera | 5.7 | 320×240 |
| NL8060BC31-27D | NLT | 12.1 | 800×600 |
| TM058WA-22L03 | SANYO | 5.8 | 400×234 |
| TM100SV-A02-01 | SANYO | 10.0 | 800×600 |
