| Nombor Bahagian | HV101WU1-1E3 |
| Jenama | HYDIS |
| Saiz | 10.1 |
| Permohonan | PAD |
| Resolusi | 1920×1200 |
| Komposisi | LCM |
| Kecerahan | 700 |
| CR | 750:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS/MIPI |
| jenama panel | HYDIS |
| model panel | HV101WU1-1E3 1 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.1 inch |
| resolusi | 1920(RGB)×1200 , WUXGA |
| mod paparan | AFFS, Normally Black, Transmissive |
| kawasan aktif | 216.576×135.36 mm |
| garis besar | 229×153×4.8 mm |
| permukaan | |
| kecerahan | 700 cd/m² (Typ.) |
| nisbah kontras | 750:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS/MIPI, 45 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
