| Nombor Bahagian | KCG057QV1DB-G500 |
| Jenama | Kyocera |
| Saiz | 5.7 |
| Permohonan | IA |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 55:1 |
| Warna | Color |
| Lampu latar | CCFL |
| Antara muka | Parallel Data |
| jenama panel | Kyocera |
| model panel | KCG057QV1DB-G500 |
| jenis panel | CSTN-LCD , LCM |
| saiz panel | 5.7 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mod paparan | STN, Normally Black, Transmissive |
| kawasan aktif | 115.2×86.4 mm |
| garis besar | 144×104.8×13.2 mm |
| permukaan | Glare (Haze 0%) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 55:1 (Typ.) |
| warna paparan | Color |
| masa tindak balas | 180/170 (Typ.)(Tr/Td) |
| sudut pandangan | 50/50/20/35 (Typ.)(CR≥2)(L/R/U/D) |
| kekerapan | 75Hz |
| jenis lampu | 1 pcsCCFLOptional |
| antara muka isyarat | Parallel Data (8-bit), 20 pins |
| voltan masukan | 3.3/5.0V (Typ.)(VDD) |
| permohonan | IA |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| EL320.240.36 ET CC | Lumineq | 5.7 | 320×240 |
| G104XGE-L05 | Innolux | 10.4 | 1024×768 |
| G121XTN01.0 | AUO | 12.1 | 1024×768 |
| LM64P101 | SHARP | 7.2 | 640×480 |
| LM64P30 | SHARP | 9.4 | 640×480 |
| LQ104S1DG2A | SHARP | 10.4 | 800×600 |
| LQ104S1LG31 | SHARP | 10.4 | 800×600 |
| NL6448BC18-03F | NLT | 5.7 | 640×480 |
| PD064VXC | E Ink | 6.4 | 640×480 |
