| Nombor Bahagian | EJ101IA-01G |
| Jenama | Innolux |
| Saiz | 10.1 |
| Permohonan | PAD |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | CHIMEI INNOLUX |
| model panel | EJ101IA-01G |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.1 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mod paparan | IPS, Normally Black, Transmissive |
| kawasan aktif | 216.96×135.6 mm |
| garis besar | 229.46×149.1×4.31 mm |
| permukaan | Hard coating |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (6-bit + Hi-FRC), CIE193150% |
| masa tindak balas | 10/15 (Typ.)(Tr/Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 3S10PWLEDWithout Driver |
| antara muka isyarat | LVDS (1 ch, 8-bit), 40 pins |
| voltan masukan | 2.5/8.2/22.0/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| permohonan | PAD |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| B101AW02 V0 | AUO | 10.1 | 1024×600 |
| B101AW03 V1 | AUO | 10.1 | 1024×600 |
| EJ101IA-01C | Innolux | 10.1 | 1280×800 |
| EJ101IA-01G | Innolux | 10.1 | 1280×800 |
| EJ101IA-02A | Innolux | 10.1 | 1280×800 |
| HSD100IFW1-F03 | HannStar | 10.1 | 1024×600 |
| HSD101PFW3-A00 | HannStar | 10.1 | 1024×600 |
| LP101WX1-SLP2 | LG Display | 10.1 | 1280×800 |
| N101L6-L0C | Innolux | 10.1 | 1024×600 |
| BP101WX1-300 | BOE | 10.1 | 1280×800 |
| HE070IA-04M | Innolux | 7.0 | 800×1280 |
| HV070WX2-1E0 | HYDIS | 7.0 | 800×1280 |
| HV101HD1-1E0 | HYDIS | 10.1 | 1366×768 |
| HV121WX4-110 | HYDIS | 12.1 | 1280×800 |
| LQ101R1SX03 | SHARP | 10.1 | 2560×1600 |
| LTL120QL01-001 | Samsung | 12.0 | 2160×1440 |
| LTN097XL02-A01 | Samsung | 9.7 | 1024×768 |
| LTN101AL03-001 | Samsung | 10.1 | 1280×800 |
| VVX10F034N00 | Panasonic | 10.1 | 1920×1200 |
