| Nombor Bahagian | AM-800600K2TMQW-04H |
| Jenama | AMPIRE |
| Saiz | 10.4 |
| Permohonan | Industrial |
| Resolusi | 800×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | AMPIRE |
| saiz panel | 10.4" |
| resolusi | 800(RGB)×600, SVGA, 96PPI |
| kawasan paparan | 211.2(W)×158.4(H) mm |
| saiz garis besar | 243(W)×185.6(H) mm |
| kecerahan | 500 cd/m² (Typ.) |
| sudut pandangan | 70/70/50/60 (Typ.)(CR≥10) |
| pandangan terbaik pada | 6 o'clock |
| warna paparan | 262K 50% NTSC |
| kekerapan | 60Hz |
| berat panel | - |
| antara muka isyarat | LVDS (1 ch, 6-bit) , 20 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -35 ~ 85 °C |
| model panel | AM-800600K2TMQW-04H |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 214.8(W)×162.7(H) mm |
| permukaan | - |
| nisbah kontras | 500:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 5/15 (Typ.)(Tr/Td) |
| jenis lampu | WLED , 30K hours , With LED Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
