| Nombor Bahagian | AM-640480VTZQW-00H |
| Jenama | AMPIRE |
| Saiz | 5.7 |
| Permohonan | Industrial |
| Resolusi | 640×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 262K |
| Lampu latar | 4S7P |
| Antara muka | CMOS |
| jenama panel | AMPIRE |
| saiz panel | 5.7" |
| resolusi | 640(RGB)×480, VGA, 141PPI |
| kawasan paparan | 115.2(W)×86.4(H) mm |
| saiz garis besar | 127(W)×98.43(H) ×6.9(D) mm |
| kecerahan | 500 cd/m² (Typ.) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 262K 63% NTSC |
| kekerapan | 60Hz |
| berat panel | - |
| antara muka isyarat | CMOS (1 ch, 6-bit) , 40 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| model panel | AM-640480VTZQW-00H |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 118.0(W)×89.2(H) mm |
| permukaan | - |
| nisbah kontras | 1200:1 (Typ.) (TM) |
| mod paparan | IPS, Normally Black, Transmissive |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| jenis lampu | 4S7P WLED , 50K hours , With LED Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
| AM-640480G2TNQW-00H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-A0H | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-T01H | AMPIRE | 5.7 | 640×480 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| AM-640480GJTNQW-TA0H | AMPIRE | 5.7 | 640×480 |
| LQ057AC111 | Other | 5.7 | 320×240 |
| TM057QDH01 | Tianma | 5.7 | 640×480 |
