| Nombor Bahagian | AM-1024600K7TMQW-T04H |
| Jenama | AMPIRE |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K |
| Lampu latar | 8S3P |
| Antara muka | |
| jenama panel | AMPIRE |
| saiz panel | 7.0" |
| resolusi | 1024(RGB)×600, WSVGA, 169PPI |
| kawasan paparan | 153.6(W)×90(H) mm |
| saiz garis besar | 165.5(W)×104.44(H) ×10.81(D) mm |
| kecerahan | 850 cd/m² (Typ.) |
| sudut pandangan | 75/75/70/75 (Typ.)(CR≥10) |
| pandangan terbaik pada | 6 o'clock |
| warna paparan | 262K |
| kekerapan | 60Hz |
| berat badan | TBD |
| model panel | AM-1024600K7TMQW-T04H |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | - |
| nisbah kontras | 700:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 20/20 (Typ.)(Tr/Td) |
| jenis lampu | 8S3P WLED , 50K hours , With LED Driver |
| skrin sentuh | PCAP |
| permohonan | Industrial |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| A070VW05 V0 | AUO | 7.0 | 800×480 |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| LB070WV4-SD01 | LG Display | 7.0 | 800×480 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
