| Nombor Bahagian | AM-1024600DTZQW-TA0H |
| Jenama | AMPIRE |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama panel | AMPIRE |
| saiz panel | 7.0" |
| resolusi | 1024(RGB)×600, WSVGA, 170PPI |
| kawasan paparan | 154.221(W)×85.92(H) mm |
| saiz garis besar | 184(W)×128(H) ×12.6(D) mm |
| kecerahan | 425 cd/m² (Typ.) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 58% NTSC |
| kekerapan | 60Hz |
| berat badan | - |
| model panel | AM-1024600DTZQW-TA0H |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | - |
| nisbah kontras | 800:1 (Typ.) (TM) |
| mod paparan | IPS, Normally Black, Transmissive |
| masa tindak balas | 13/15 (Typ.)(Tr/Td) |
| jenis lampu | WLED , 30K hours , With LED Driver |
| skrin sentuh | PCAP |
| permohonan | Industrial |
