| Nombor Bahagian | A062EAN01.0 |
| Jenama | AUO |
| Saiz | 6.2 |
| Permohonan | Home Appliance |
| Resolusi | 1280×720 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | |
| jenama | AUO |
| saiz pepenjuru | 6.2 inch |
| format piksel | 1280(RGB)×720 [WXGA] 237PPI |
| kawasan aktif | 137.088(H)×77.112(V) mm |
| kawasan bezel | - |
| kecerahan | 0 cd/m² |
| arah pandang | Symmetry |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| ketebalan plat | 0.20+0.20 mm |
| warna sokongan | 16.7M 71% NTSC |
| berat badan | TBD |
| kadar bingkai | 60Hz |
| perincian d-ic | COG Suggest HX8394-F |
| persekitaran | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
| model | A062EAN01.0 |
| menaip | a-Si TFT-LCD , CELL |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 145.338(H)×81.712(V) ×0.63(D) mm |
| rawatan | Antiglare, Hard coating (3H) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| masa tindak balas | 15/12 (Typ.)(Tr/Td) |
| mod operasi | AHVA, Normally Black, Transmissive |
| penghantaran | 4.64% (Typ.)(with Polarizer) |
| sumber cahaya | No B/L |
| direka untuk | Home Appliance |
| panel sentuh | Without |
| CLAA062LA01CW | CPT | 6.2 | 800×480 |
| HSD062IDW1-A00 | HannStar | 6.2 | 800×480 |
| PM062HT1 | E Ink | 6.2 | 640×240 |
| PW062XS6 | E Ink | 6.2 | 480×234 |
| PW062XU7 | E Ink | 6.2 | 480×234 |
| PW062XU8 | E Ink | 6.2 | 480×234 |
| TM062RDH03 | Tianma | 6.2 | 800×480 |
| TM062RDZG10 | Tianma | 6.2 | 800×480 |
| TX16D11VM2CCA | KOE | 6.2 | 640×240 |
| TX16D18VM2CAB | KOE | 6.2 | 800×300 |
