| Nombor Bahagian | CLAA062LA01CW |
| Jenama | CPT |
| Saiz | 6.2 |
| Permohonan | CNS |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 450 |
| CR | 600:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | CPT |
| model panel | CLAA062LA01CW |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 6.2 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 137.52×77.323 mm |
| garis besar | 155.2×88.2×5.3 mm |
| permukaan | Antiglare |
| kecerahan | 450 cd/m² (Typ.) |
| nisbah kontras | 600:1 (Typ.) |
| warna paparan | 16.2M (6-bit + FRC), CIE193150% |
| masa tindak balas | 16 (Typ.)(Tr+Td) |
| sudut pandangan | 75/75/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 3S6PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 8-bit), 60 pins |
| voltan masukan | 3.3/9.2/18/-6.0/-4.0V (Typ.)(DVDD/AVDD/VDDG/VEEG/VCOM) |
| permohonan | CNS |
