| Nombor Bahagian | TX16D18VM2CAB |
| Jenama | KOE |
| Saiz | 6.2 |
| Permohonan | IA |
| Resolusi | 800×300 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 200:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | HITACHI |
| model panel | TX16D18VM2CAB |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 6.2 inch |
| resolusi | 800(RGB)×300 , HSVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 148.8×53.76 mm |
| garis besar | 173×70 mm |
| permukaan | |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 200:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193160% |
| masa tindak balas | 45 (Typ.)(Tr+Td) |
| sudut pandangan | 70/70/50/80 (Typ.)(CR≥5)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 3S7PWLEDWithout Driver |
| antara muka isyarat | CMOS (1 ch, 6-bit), 40 pins |
| voltan masukan | 3.3V (Typ.)(VDD) |
| permohonan | IA |
