| Nombor Bahagian | PW062XU7 |
| Jenama | E Ink |
| Saiz | 6.2 |
| Permohonan | CNS |
| Resolusi | 480×234 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 350:1 |
| Warna | Full color |
| Lampu latar | CCFL |
| Antara muka | Analog |
| jenama panel | PVI |
| model panel | PW062XU7 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 6.2 inch |
| resolusi | 480(RGB)×234 |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 137.52×77.22 mm |
| garis besar | 154.4×92.6×6.2 mm |
| permukaan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 350:1 (Typ.) |
| warna paparan | Full color |
| masa tindak balas | 15/25 (Typ.)(Tr/Td) |
| sudut pandangan | 60/60/35/50 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | TFT Specific Analog RGB, 26 pins |
| voltan masukan | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL) |
| permohonan | CNS |
| C043FW01 V0 | AUO | 4.3 | 480×234 |
| C065GW03 V3 | AUO | 6.5 | 400×240 |
| C070VW04 V5 | AUO | 7.0 | 800×480 |
| HSD062IDW1-A00 | HannStar | 6.2 | 800×480 |
| LAJ080W001A | TPO | 8.0 | 800×480 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LQ038Q5DR01 | SHARP | 3.8 | 320×240 |
| LQ049B5DG04 | SHARP | 4.9 | 320×96 |
| PW062XU7 | E Ink | 6.2 | 480×234 |
| PW065XS1 | E Ink | 6.5 | 400×234 |
