| Nombor Bahagian | ET035009DH6 |
| Jenama | EDT |
| Saiz | 3.5 |
| Permohonan | IA |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 400:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | EDT |
| model panel | ET035009DH6 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 3.5 inch |
| resolusi | 320(RGB)×240 , QVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 70.08×52.56 mm |
| garis besar | 76.8×63.8 mm |
| permukaan | |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) |
| warna paparan | 16.7M (8-bit) |
| masa tindak balas | 15/35 (Typ.)(Tr/Td) |
| sudut pandangan | 75/75/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 6S1PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| voltan masukan | 3.3/3.3V (Typ.)(VCC/VDD) |
| permohonan | IA |
| ACX502BMU-7 | SONY | 3.5 | 240×320 |
| COM35H3P09UTC | ORTUSTECH | 3.5 | 480×640 |
| EL160.80.50 ET | Lumineq | 3.5 | 160×80 |
| ET035009DH6 | EDT | 3.5 | 320×240 |
| LH350H01-FD01 | LG Display | 3.5 | 320×480 |
| LTV035QV-F09 | Samsung | 3.5 | 320×240 |
| NL2432DR22-02B | NLT | 3.5 | 240×320 |
| NL2432HC22-32B | NLT | 3.5 | 240×320 |
| NL4864HL11-01B | NLT | 3.5 | 480×640 |
| PD035QX2 | E Ink | 3.5 | 320×240 |
| AA065VE11ADA11 | Mitsubishi | 6.5 | 640×480 |
| AA104VC06 | Mitsubishi | 10.4 | 640×480 |
| AT104XH11 | Mitsubishi | 10.4 | 1024×768 |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| G156HAN01.0 | AUO | 15.6 | 1920×1080 |
| LQ9D023 | SHARP | 8.4 | 640×480 |
| M121MNS1 R0 | IVO | 12.1 | 800×600 |
| MD400T640PD1 | Panasonic | 9.4 | 640×400 |
| PD064VT8 | E Ink | 6.4 | 640×480 |
| TS104SAALC01-00 | Tianma | 10.4 | 800×600 |
