| Nombor Bahagian | WG16080C1-YGH-VZ# |
| Jenama | Winstar |
| Saiz | 3.0 |
| Permohonan | Industrial Instrumen |
| Resolusi | 160×80 |
| Komposisi | STN-LCD , LCM |
| Kecerahan | |
| CR | 3:1 |
| Warna | Monochrome |
| Lampu latar | YG-LED |
| Antara muka | |
| jenama | Winstar |
| saiz pepenjuru | 3.0 inch |
| format piksel | 160×80 60PPI |
| kawasan aktif | 67.17(H)×33.57(V) mm |
| kawasan bezel | 72.0(H)×40.0(V) mm |
| kecerahan | - |
| arah pandang | 6 o'clock |
| sudut pandangan | 30/30/20/40 (Max.)(CR≥2) |
| warna sokongan | Monochrome |
| berat badan | - |
| kadar bingkai | - |
| model | WG16080C1-YGH-VZ# |
| menaip | STN-LCD , LCM |
| konfigurasi | Rectangle |
| garis besar malap. | 100(H)×54(V) ×14.6(D) mm |
| rawatan | - |
| nisbah kontras | 3:1 (Typ.) (TM) |
| masa tindak balas | 200/250 (Typ.)(Tr/Td) |
| mod operasi | STN, Blue/Grey (Positive), Transflective |
| sumber cahaya | YG-LED , 100K hours , W/O Driver |
| direka untuk | Industrial Instruments & Meters |
| panel sentuh | Without |
