WG12232J-YYH-V#A

WG12232J-YYH-V#A
WG12232J-YYH-V#A
WG12232J-YYH-V#A thumb WG12232J-YYH-V#A thumb
Jenama
Winstar
Saiz
2.2
Permohonan
Industrial Instrumen
Resolusi
122×32
Komposisi
STN-LCD, LCM
Kecerahan
CR
3:1
Warna
Monochrome
Lampu latar
YG-LED
Antara muka
8-bit
In Stock
12252
Spesifikasi

Nombor Bahagian WG12232J-YYH-V#A
JenamaWinstar
Saiz2.2
PermohonanIndustrial Instrumen
Resolusi122×32
KomposisiSTN-LCD, LCM
Kecerahan
CR3:1
WarnaMonochrome
Lampu latarYG-LED
Antara muka8-bit
jenamaWinstar
modelWG12232J-YYH-V#A
saiz pepenjuru2.2 inch
menaipSTN-LCD, LCM
format piksel122×32  57PPI
konfigurasiRectangle
kawasan aktif53.64(H)×15.64(V) mm
garis besar malap.80(H)×36(V) ×13.7(D) mm
kawasan bezel60.0(H)×18.0(V) mm
rawatan-
kecerahan-
nisbah kontras3:1 (Typ.) (TM)
arah pandang6 o'clock
masa tindak balas150/150 (Typ.)(Tr/Td)
sudut pandangan30/30/20/40 (Max.)(CR≥2)
mod operasiSTN, Yellow/Green (Positive), Transflective
warna sokonganMonochrome
sumber cahayaYG-LED , 100K hours , W/O Driver
berat badan-
direka untukIndustrial Instruments & Meters
kadar bingkai-
panel sentuhWithout
jenis antara muka8-bit 6800/8080 parallel , 20 pins Pad
bekalan kuasa3.0V (Typ.)
persekitaranOperating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
