| Nombor Bahagian | WG12232E-YYH-N#A |
| Jenama | Winstar |
| Saiz | 2.2 |
| Permohonan | Industrial Instrumen |
| Resolusi | 122×32 |
| Komposisi | STN-LCD , LCM |
| Kecerahan | |
| CR | 3:1 |
| Warna | Monochrome |
| Lampu latar | YG-LED |
| Antara muka | 8-bit |
| jenama | Winstar |
| saiz pepenjuru | 2.2 inch |
| format piksel | 122×32 57PPI |
| kawasan aktif | 53.64(H)×15.64(V) mm |
| kawasan bezel | 60.0(H)×18.0(V) mm |
| kecerahan | - |
| arah pandang | 6 o'clock |
| sudut pandangan | 30/30/20/40 (Typ.)(CR≥2) |
| warna sokongan | Monochrome |
| berat badan | - |
| kadar bingkai | - |
| jenis antara muka | 8-bit 6800/8080 parallel , 20 pins Pad |
| bekalan kuasa | 5.0V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | WG12232E-YYH-N#A |
| menaip | STN-LCD , LCM |
| konfigurasi | Rectangle |
| garis besar malap. | 80(H)×36(V) ×10.2(D) mm |
| rawatan | - |
| nisbah kontras | 3:1 (Typ.) (TM) |
| masa tindak balas | 100/100 (Typ.)(Tr/Td) |
| mod operasi | STN, Yellow/Green (Positive), Transflective |
| sumber cahaya | YG-LED , 100K hours , W/O Driver |
| direka untuk | Industrial Instruments & Meters |
| panel sentuh | Without |
