| Nombor Bahagian | WF57STIACDNG0 |
| Jenama | Winstar |
| Saiz | 5.7 |
| Permohonan | Industrial |
| Resolusi | 320×240 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | Grayscale |
| Lampu latar | WLED |
| Antara muka | 8/16-bit |
| jenama | Winstar |
| saiz pepenjuru | 5.7 inch |
| format piksel | 320×240 [QVGA] 70PPI |
| kawasan aktif | 115.2(H)×86.4(V) mm |
| kawasan bezel | 117.9(H)×89.1(V) mm |
| kecerahan | 800 cd/m² (Typ.) |
| arah pandang | 12 o'clock |
| sudut pandangan | - |
| warna sokongan | Grayscale |
| berat badan | - |
| kadar bingkai | - |
| jenis antara muka | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | WF57STIACDNG0 |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | Rectangle |
| garis besar malap. | 160(H)×109(V) ×9.24(D) mm |
| rawatan | Glare (Haze 0%) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| masa tindak balas | - |
| mod operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED , W/O Driver |
| direka untuk | Industrial |
| panel sentuh | PCAP |
