| Nombor Bahagian | SP14Q001 |
| Jenama | KOE |
| Saiz | 5.7 |
| Permohonan | IA |
| Resolusi | 320×240 |
| Komposisi | LCM |
| Kecerahan | 80 |
| CR | 6:1 |
| Warna | Monochrome |
| Lampu latar | CCFL |
| Antara muka | Parallel Data |
| jenama panel | HITACHI |
| model panel | SP14Q001 |
| jenis panel | STN-LCD , LCM |
| saiz panel | 5.7 inch |
| resolusi | 320×240 , QVGA |
| mod paparan | STN, Blue mode (Negative), Transmissive |
| kawasan aktif | 115.185×86.385 mm |
| garis besar | 167×109×10 mm |
| permukaan | Antiglare |
| kecerahan | 80 cd/m² (Typ.) |
| nisbah kontras | 6:1 (Typ.) |
| warna paparan | Monochrome |
| masa tindak balas | 120/150 (Typ.)(Tr/Td) |
| sudut pandangan | 40 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| kekerapan | 75Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel Data (4-bit), 14 pins |
| voltan masukan | 5.0V (Typ.) |
| permohonan | IA |
