| Nombor Bahagian | WEO012864DG |
| Jenama | Winstar |
| Saiz | 0.96 |
| Permohonan | Handheld & PDA Healt |
| Resolusi | 128×64 |
| Komposisi | OLED , PM-OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(Green) |
| Lampu latar | self |
| Antara muka | 8-bit |
| pengilang | Winstar |
| saiz skrin | 0.96 inch |
| nombor piksel | 128×64 149PPI |
| kawasan aktif (mm) | 21.738 × 10.858 (H×V) |
| kawasan bezel (mm) | 23.938 × 12.058 (H×V) |
| sudut pandangan | - |
| pandangan yang baik di | Symmetry |
| kedalaman warna | Mono(Green) |
| jisim | - |
| kadar segar semula | - |
| senarai ic pemandu | Built-in COG SSD1306BZ |
| jenis isyarat | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 30 pins FPC |
| bekalan voltan | 3.0V (Typ.) |
| nama model | WEO012864DG |
| jenis skrin | OLED , PM-OLED |
| susunan | Rectangle |
| garis besar (mm) | 26.7 × 19.26 × 1.81 (H×V×D) |
| rawatan | - |
| tindak balas | - |
| mod kerja | - |
| lampu latar | self |
| digunakan untuk | Handheld & PDA Healthcare Instruments & Meters |
| skrin sentuh | Without |
| IROP018-010-0128064-W | Other | 0.96 | 128×64 |
| L3P10Y-81G00 | Epson | 0.96 | 1400×1050 |
| OEL9M0083-B-E | Other | 0.96 | 128×64 |
| OEL9M0083-R-E | Other | 0.96 | 128×64 |
| OEL9M0083-W-E | Other | 0.96 | 128×64 |
| OEL9M0083-Y-E | Other | 0.96 | 128×64 |
| RGS10096096WR001 | RiTdisplay | 0.96 | 96×96 |
| RGS10128064WR010 | RiTdisplay | 0.96 | 128×64 |
| UG-2864HLBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HMBEG01 | WiseChip | 0.96 | 128×64 |
