| Nombor Bahagian | WEO009664AW |
| Jenama | Winstar |
| Saiz | 0.95 |
| Permohonan | Wearable MP3 PMP |
| Resolusi | 96×64 |
| Komposisi | OLED , PM-OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(White) |
| Lampu latar | self |
| Antara muka | 8-bit |
| pengilang | Winstar |
| saiz skrin | 0.95 inch |
| nombor piksel | 96×64 121PPI |
| kawasan aktif (mm) | 19.946 × 13.418 (H×V) |
| kawasan bezel (mm) | 21.953 × 15.424 (H×V) |
| sudut pandangan | - |
| pandangan yang baik di | Symmetry |
| kedalaman warna | Mono(White) |
| jisim | - |
| kadar segar semula | - |
| senarai ic pemandu | Built-in COG SSD1305Z |
| jenis isyarat | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 25 pins FPC |
| bekalan voltan | 3.0V (Typ.) |
| maks. penilaian | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 80 °C |
| nama model | WEO009664AW |
| jenis skrin | OLED , PM-OLED |
| susunan | Rectangle |
| garis besar (mm) | 24.9 × 22.95 × 1.95 (H×V×D) |
| rawatan | - |
| tindak balas | - |
| mod kerja | - |
| lampu latar | self |
| digunakan untuk | Wearable MP3 PMP |
| skrin sentuh | Without |
