| Nombor Bahagian | WEF012864QS |
| Jenama | Winstar |
| Saiz | 2.7 |
| Permohonan | Home Appliance Handh |
| Resolusi | 128×64 |
| Komposisi | PM-OLED , OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(Blue) |
| Lampu latar | self |
| Antara muka | 8-bit |
| jenama panel | Winstar |
| saiz panel | 2.7" |
| resolusi | 128×64, 52PPI |
| kawasan paparan | 61.41(W)×30.69(H) mm |
| saiz garis besar | 89.7(W)×47.2(H) mm |
| sudut pandangan | - |
| pandangan terbaik pada | Symmetry |
| warna paparan | Mono(Blue) |
| kekerapan | - |
| ic pemandu | COG Built-in SSD1309ZC |
| berat panel | - |
| antara muka isyarat | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 30 pins FPC |
| voltan masukan | 3.0/13V (Typ.)(VDD/VCC) |
| persekitaran | Operating Temp.: -40 ~ 80 °C ; Storage Temp.: -40 ~ 80 °C |
| model panel | WEF012864QS |
| jenis panel | PM-OLED , OLED |
| format piksel | Rectangle |
| pembukaan bezel | 63.41(W)×32.69(H) mm |
| permukaan | - |
| mod paparan | - |
| masa tindak balas | - |
| jenis lampu | self |
| skrin sentuh | Without |
| permohonan | Home Appliance Handheld & PDA Healthcare Instruments & Meters |
