| Nombor Bahagian | WEA012864DWPP3N00003 |
| Jenama | Winstar |
| Saiz | 0.96 |
| Permohonan | Instruments & Me |
| Resolusi | 128×64 |
| Komposisi | PM-OLED, OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(White) |
| Lampu latar | self |
| Antara muka | I²C |
| jenama panel | Winstar |
| model panel | WEA012864DWPP3N00003 |
| saiz panel | 0.96" |
| jenis panel | PM-OLED, OLED |
| resolusi | 128×64, 149PPI |
| format piksel | Rectangle |
| kawasan paparan | 21.74(W)×10.86(H) mm |
| pembukaan bezel | 23.94(W)×12.06(H) mm |
| saiz garis besar | 27.3(W)×27.3(H) ×4.37(D) mm |
| permukaan | - |
| sudut pandangan | - |
| mod paparan | - |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | - |
| warna paparan | Mono(White) |
| jenis lampu | self |
| kekerapan | - |
| skrin sentuh | Without |
| ic pemandu | COGBuilt-in SSD1306BZ |
| berat panel | - |
| permohonan | Instruments & Meters |
| antara muka isyarat | I²C , 4 pins PIN |
| voltan masukan | 3.0/5.0V (Min./Max.) |
| persekitaran | Operating Temp.: -40 ~ 80 °C ; Storage Temp.: -40 ~ 85 °C |
| IROP018-010-0128064-W | Other | 0.96 | 128×64 |
| L3P10Y-81G00 | Epson | 0.96 | 1400×1050 |
| OEL9M0083-B-E | Other | 0.96 | 128×64 |
| OEL9M0083-R-E | Other | 0.96 | 128×64 |
| OEL9M0083-W-E | Other | 0.96 | 128×64 |
| RGS10096096WR001 | RiTdisplay | 0.96 | 96×96 |
| RGS10128064WR010 | RiTdisplay | 0.96 | 128×64 |
| UG-2864HLBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HMBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HSWEG01 | WiseChip | 0.96 | 128×64 |
