| Nombor Bahagian | WEA012864DLPP3N00001 |
| Jenama | Winstar |
| Saiz | 0.96 |
| Permohonan | Instruments & Me |
| Resolusi | 128×64 |
| Komposisi | PM-OLED, OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(Yellow) |
| Lampu latar | self |
| Antara muka | 4-wire |
| jenama panel | Winstar |
| model panel | WEA012864DLPP3N00001 |
| saiz panel | 0.96" |
| jenis panel | PM-OLED, OLED |
| resolusi | 128×64, 149PPI |
| format piksel | Rectangle |
| kawasan paparan | 21.74(W)×10.86(H) mm |
| pembukaan bezel | 23.94(W)×12.06(H) mm |
| saiz garis besar | 38(W)×28.5(H) ×4.37(D) mm |
| permukaan | - |
| sudut pandangan | - |
| mod paparan | - |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | - |
| warna paparan | Mono(Yellow) |
| jenis lampu | self |
| kekerapan | - |
| skrin sentuh | Without |
| ic pemandu | COG Built-in SSD1306BZ |
| berat panel | - |
| permohonan | Instruments & Meters |
| antara muka isyarat | 4-wire SPI, I²C , 8 pins PIN |
| voltan masukan | 3.3/5.0/7.5V (Typ.) |
| persekitaran | Operating Temp.: -40 ~ 80 °C ; Storage Temp.: -40 ~ 85 °C |
