| Nombor Bahagian | V580DJ4-Q01 |
| Jenama | Innolux |
| Saiz | 58 |
| Permohonan | TV Sets |
| Resolusi | 3840×2160 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 5000:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antara muka | V-by-One |
| jenama panel | Innolux |
| saiz panel | 58" |
| resolusi | 3840(RGB)×2160, UHD, 76PPI |
| kawasan paparan | 1270.08(W)×721.44(H) mm |
| saiz garis besar | 1283.38(W)×734.69(H) ×1.32(D) mm |
| kecerahan | 0 cd/m² |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| kedalaman kaca | - |
| warna paparan | 1.07B 71% NTSC |
| kekerapan | 60Hz |
| ic pemandu | COF Built-in 12 source chips |
| berat panel | 2.80Kgs (Typ.) |
| antara muka isyarat | V-by-One 8 lane , 51 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | V580DJ4-Q01 |
| jenis panel | a-Si TFT-LCD , CELL |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Hard coating (3H), Reflection 1.8% (Typ.) |
| nisbah kontras | 5000:1 (Typ.) (TM) |
| mod paparan | Super MVA, Normally Black, Transmissive |
| masa tindak balas | 9.5 (Typ.)(G to G) |
| ketransmisian | 5.8% (Typ.)(with Polarizer) |
| jenis lampu | No B/L |
| skrin sentuh | Without |
| permohonan | TV Sets |
