| Nombor Bahagian | V580DK1-LS1 |
| Jenama | Innolux |
| Saiz | 58 |
| Permohonan | LCTV |
| Resolusi | 3840×2160 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 5000:1 |
| Warna | 1.07B |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | CHIMEI INNOLUX |
| model panel | V580DK1-LS1 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 58 inch |
| resolusi | 3840(RGB)×2160 , UHD |
| mod paparan | Super MVA, Normally Black, Transmissive |
| kawasan aktif | 1270.08×721.44 mm |
| garis besar | 1290.3×744.7×28.6 mm |
| permukaan | Antiglare (Haze 1%) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 5000:1 (Typ.) |
| warna paparan | 1.07B (8-bit + Hi-FRC), CIE193172% |
| masa tindak balas | 6.5 (Typ.)(G to G) |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| kekerapan | 120Hz (30Hz Input) |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (4 ch, 10-bit), 102 pins |
| voltan masukan | 12.0V (Typ.) |
| permohonan | LCTV |
