V580DK2-KS1 Rev.C8

V580DK2-KS1 Rev.C8
V580DK2-KS1 Rev.C8
V580DK2-KS1 Rev.C8
V580DK2-KS1 Rev.C8 thumb V580DK2-KS1 Rev.C8 thumb V580DK2-KS1 Rev.C8 thumb
Jenama
Innolux
Saiz
58
Permohonan
LCTV
Resolusi
3840×2160
Komposisi
LCM
Kecerahan
400
CR
4000:1
Warna
1.07B
Lampu latar
WLED
Antara muka
V-by-One
In Stock
18000
Spesifikasi

Nombor Bahagian V580DK2-KS1 Rev.C8
JenamaInnolux
Saiz58
PermohonanLCTV
Resolusi3840×2160
KomposisiLCM
Kecerahan400
CR4000:1
Warna1.07B
Lampu latarWLED
Antara mukaV-by-One
jenama panelCHIMEI INNOLUX
model panelV580DK2-KS1 Rev.C8
jenis panel a-Si TFT-LCD , LCM
saiz panel58 inch
resolusi3840(RGB)×2160 , UHD
mod paparanSuper MVA, Normally Black, Transmissive
kawasan aktif1270.08×721.44 mm
garis besar1290.3×744.7×28.6 mm
permukaanAntiglare (Haze 1%)
kecerahan400 cd/m² (Typ.)
nisbah kontras4000:1 (Typ.)
warna paparan1.07B (8-bit + Hi-FRC), CIE193172%
masa tindak balas9.5 (Typ.)(G to G)
sudut pandangan88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
kekerapan120Hz
jenis lampuWLEDEmbedded (LED Driver)
antara muka isyaratV-by-One 8 lane, 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
