Innolux V500HK1-PS6 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


V500HK1-PS6

V500HK1-PS6
V500HK1-PS6
V500HK1-PS6 thumb V500HK1-PS6 thumb
Jenama
Innolux
Saiz
50
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
CELL
Kecerahan
0
CR
5000:1
Warna
16.7M
Lampu latar
No B/L
Antara muka
LVDS
In Stock
181
Spesifikasi

Nombor Bahagian V500HK1-PS6
JenamaInnolux
Saiz50
PermohonanLCTV
Resolusi1920×1080
KomposisiCELL
Kecerahan0
CR5000:1
Warna16.7M
Lampu latarNo B/L
Antara mukaLVDS
jenama panelCHIMEI INNOLUX
model panelV500HK1-PS6
jenis panel a-Si TFT-LCD , CELL
saiz panel50 inch
resolusi1920(RGB)×1080 , FHD
mod paparanSuper MVA, Normally Black, Transmissive
kawasan aktif1095.84×616.41 mm
garis besar1122.32×668.06 mm
permukaanAntiglare (Haze 1%)
kedalaman kaca0.70+0.70 mm
ketransmisian5.0% (Typ.)(with Polarizer)
nisbah kontras5000:1 (Typ.)
warna paparan16.7M (8-bit)
masa tindak balas9.5 (Typ.)(G to G)
sudut pandangan88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
kekerapan120Hz (60Hz Input)
antara muka isyaratLVDS (2 ch, 8-bit), 61 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
V500HJ1-L01 Innolux 50 1920×1080
V500HJ1-LE2 Innolux 50 1920×1080
V500HJ1-PE8 Innolux 50 1920×1080
V500HK1-LE1 Innolux 50 1920×1080
V500HK1-LE6 Innolux 50 1920×1080
V500HK1-LS5 Innolux 50 1920×1080
V500HK1-LS6 Rev.C7 Innolux 50 1920×1080
V500HK1-LS6 Rev.E7 Innolux 50 1920×1080
V500HK1-PS6 Innolux 50 1920×1080
V500HK2-PS1 Innolux 50 1920×1080
