V500HK1-LS6 Rev.E7

V500HK1-LS6 Rev.E7
V500HK1-LS6 Rev.E7
V500HK1-LS6 Rev.E7
V500HK1-LS6 Rev.E7 thumb V500HK1-LS6 Rev.E7 thumb V500HK1-LS6 Rev.E7 thumb
Jenama
Innolux
Saiz
50
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
350
CR
5000:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
130
Spesifikasi

Nombor Bahagian V500HK1-LS6 Rev.E7
JenamaInnolux
Saiz50
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan350
CR5000:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelCHIMEI INNOLUX
model panelV500HK1-LS6 Rev.E7
jenis panel a-Si TFT-LCD , LCM
saiz panel50 inch
resolusi1920(RGB)×1080 , FHD
mod paparanSuper MVA, Normally Black, Transmissive
kawasan aktif1095.84×616.41 mm
garis besar1115.04×638.41×27 mm
permukaanAntiglare (Haze 1%)
kecerahan350 cd/m² (Typ.)
nisbah kontras5000:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas6.5 (Typ.)(G to G)
sudut pandangan88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
kekerapan120Hz (60Hz Input)
jenis lampuWLEDEmbedded (LED Driver)
antara muka isyaratLVDS (2 ch, 8-bit), 61 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
T500HVN04.6 AUO 50 1920×1080
V500HJ1-L01 Innolux 50 1920×1080
V500HJ1-LE8 Innolux 50 1920×1080
V500HJ1-PE6 Innolux 50 1920×1080
V500HK1-LE1 Innolux 50 1920×1080
V500HK1-LE6 Innolux 50 1920×1080
V500HK1-LS5 Innolux 50 1920×1080
V500HK1-LS6 Rev.C7 Innolux 50 1920×1080
V500HK1-LS6 Rev.E7 Innolux 50 1920×1080
V500HK2-PS1 Innolux 50 1920×1080
