| Nombor Bahagian | TV101WXM-NS0 |
| Jenama | BOE |
| Saiz | 10.1 |
| Permohonan | Pad & Tablet |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | 6 |
| Antara muka | LVDS |
| jenama panel | BOE |
| saiz panel | 10.1" |
| resolusi | 1280(RGB)×800, WXGA, 149PPI |
| kawasan paparan | 216.96(W)×135.6(H) mm |
| saiz garis besar | 228.211(W)×148.86(H) ×4.59(D) mm |
| kecerahan | - |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 50% NTSC |
| kekerapan | 60Hz |
| berat panel | 130g (Typ.) |
| antara muka isyarat | LVDS (1 ch, 8-bit) , 45 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 65 °C ; Storage Temp.: -40 ~ 80 °C |
| model panel | TV101WXM-NS0 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Hard coating (2H), Antireflection |
| nisbah kontras | 900:1 (Typ.) (TM) |
| mod paparan | ADS, Normally Black, Transmissive |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| jenis lampu | 6 strings WLED , Without Driver |
| skrin sentuh | Without |
| permohonan | Pad & Tablet |
