| Nombor Bahagian | TV101WUM-NW1 |
| Jenama | No Brand |
| Saiz | 10.1 |
| Permohonan | Pad & Tablet |
| Resolusi | 1200×1920 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 8S4P |
| Antara muka | MIPI |
| jenama panel | No Brand |
| saiz panel | 10.1" |
| resolusi | 1200(RGB)×1920, WUXGA, 225PPI |
| kawasan paparan | 135.36(W)×216.576(H) mm |
| saiz garis besar | 142.76(W)×228.18(H) ×4.2(D) mm |
| kecerahan | 450 cd/m² (Typ.) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 100% sRGB |
| kekerapan | 60Hz |
| berat panel | TBD |
| antara muka isyarat | MIPI (4 data lanes) , 40 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
| model panel | TV101WUM-NW1 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Clear, Hard coating |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| mod paparan | HADS, Normally Black, Transmissive |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| jenis lampu | 8S4P WLED , Without Driver |
| skrin sentuh | Without |
| permohonan | Pad & Tablet |
