| Nombor Bahagian | TV101WUM-LL3 |
| Jenama | BOE |
| Saiz | 10.1 |
| Permohonan | Pad & Tablet |
| Resolusi | 1200×1920 |
| Komposisi | a-Si TFT-LCD, Assemb |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | BOE |
| model | TV101WUM-LL3 |
| saiz pepenjuru | 10.1 inch |
| menaip | a-Si TFT-LCD, Assembly |
| format piksel | 1200(RGB)×1920 [WUXGA] 225PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 135.36(H)×216.576(V) mm |
| garis besar malap. | 163.1(H)×237.14(V) mm |
| kawasan bezel | - |
| rawatan | Hard coating |
| kecerahan | 320 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Min.)(CR≥10) |
| mod operasi | HADS, Normally Black, Transmissive |
| warna sokongan | 16.7M 71% NTSC |
| sumber cahaya | WLED [8S4P] , W/O Driver |
| berat badan | 225g (Typ.) |
| direka untuk | Pad & Tablet |
| kadar bingkai | 60Hz |
| panel sentuh | In-Cell Touch |
| Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
