| Nombor Bahagian | TV096WXM-NS0 |
| Jenama | BOE |
| Saiz | 9.6 |
| Permohonan | PAD |
| Resolusi | 800×1280 |
| Komposisi | LCM |
| Kecerahan | 450 |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | BOE |
| model panel | TV096WXM-NS0 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 9.6 inch |
| resolusi | 800(RGB)×1280 , WXGA |
| mod paparan | ADS, Normally Black, Transmissive |
| kawasan aktif | 129×206.4 mm |
| garis besar | 136.7×217×4.65 mm |
| permukaan | Hard coating, Antireflection |
| kecerahan | 450 cd/m² (Typ.) |
| nisbah kontras | 900:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193147% |
| masa tindak balas | |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 7S4PWLEDWithout Driver |
| antara muka isyarat | MIPI (4 data lanes), 34 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
