| Nombor Bahagian | TV080WUM-NK0 |
| Jenama | BOE |
| Saiz | 8.0 |
| Permohonan | Pad & Tablet |
| Resolusi | 1200×1920 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 850:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama | BOE |
| model | TV080WUM-NK0 |
| saiz pepenjuru | 8.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1200(RGB)×1920 [WUXGA] 283PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 107.64(H)×172.224(V) mm |
| garis besar malap. | - |
| kecerahan | - |
| nisbah kontras | 850:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | ADS, Normally Black, Transmissive |
| warna sokongan | 16.7M 63% NTSC |
| sumber cahaya | WLED |
| berat badan | - |
| direka untuk | Pad & Tablet |
| kadar bingkai | 60Hz |
| panel sentuh | - |
| jenis antara muka | MIPI (4 data lanes) , 39 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
