| Nombor Bahagian | TP241MC01G |
| Jenama | Neoview Kolon |
| Saiz | 2.4 |
| Permohonan | MPH |
| Resolusi | 240×320 |
| Komposisi | OLED |
| Kecerahan | 140 |
| CR | |
| Warna | 16.7M |
| Lampu latar | self |
| Antara muka | CPU/SPI |
| jenama panel | Neoview Kolon |
| model panel | TP241MC01G |
| jenis panel | TOLED , OLED |
| saiz panel | 2.4 inch |
| resolusi | 240(RGB)×320 , QVGA |
| kawasan aktif | 36.72×48.96 mm |
| garis besar | 42.92×59.46×1.5 mm |
| permukaan | |
| kecerahan | 140 cd/m² (Typ.) |
| nisbah kontras | |
| warna paparan | 16.7M (8-bit) |
| sudut pandangan | |
| ic pemandu | Built-in DA8620 |
| antara muka isyarat | 8-bit 8080 parallel, SPI, 39 pins |
| voltan masukan | 18.0V (Typ.) |
| rohs: | |
| permohonan | MPH |
