| Nombor Bahagian | H430VL02 V4 |
| Jenama | AUO |
| Saiz | 4.3 |
| Permohonan | MPH |
| Resolusi | 480×800 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | AUO |
| model panel | H430VL02 V4 |
| jenis panel | LTPS TFT-LCD , LCM |
| saiz panel | 4.3 inch |
| resolusi | 480(RGB)×800 , WVGA |
| mod paparan | MVA, Normally Black, Transmissive |
| kawasan aktif | 56.16×93.6 mm |
| garis besar | 62.46×105.9 mm |
| permukaan | |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193170% |
| masa tindak balas | 20/15 (Typ.)(Tr/Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | WLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 8-bit) |
| permohonan | MPH |
