| Nombor Bahagian | TM123XDHP01 |
| Jenama | TIANMA |
| Saiz | 12.3 |
| Permohonan | Industrial Automotiv |
| Resolusi | 1920×720 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | TIANMA |
| saiz pepenjuru | 12.3 inch |
| format piksel | 1920(RGB)×720 166PPI |
| kawasan aktif | 292.32(H)×109.62(V) mm |
| kecerahan | - |
| arah pandang | Symmetry |
| sudut pandangan | - |
| warna sokongan | 16.7M sRGB |
| berat badan | - |
| kadar bingkai | 60Hz |
| persekitaran | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
| model | TM123XDHP01 |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | - |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| mod operasi | SFT, Normally Black, Transmissive |
| sumber cahaya | WLED |
| direka untuk | Industrial Automotive Display |
| panel sentuh | Without |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
