| Nombor Bahagian | TJ123NP01CA |
| Jenama | Innolux |
| Saiz | 12.3 |
| Permohonan | CNS |
| Resolusi | 1280×480 |
| Komposisi | LCM |
| Kecerahan | 1000 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL/RSDS |
| jenama panel | INNOLUX |
| model panel | TJ123NP01CA |
| jenis panel | LTPS TFT-LCD , LCM |
| saiz panel | 12.3 inch |
| resolusi | 1280(RGB)×480 , DVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 291.84×109.44 mm |
| garis besar | 333.8×134.6×44.1 mm |
| permukaan | |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193155% |
| masa tindak balas | 5/15 (Typ.)(Tr/Td) |
| sudut pandangan | 60/60/55/55 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 4S4PWLEDWithout Driver |
| antara muka isyarat | TTL/RSDS (1 ch, 6-bit), 50 pins |
| voltan masukan | 3.3/8.0/-12.0V (Typ.)(VCC/VGH/VGL) |
| permohonan | CNS |
