| Nombor Bahagian | TM080TDHG01-42 |
| Jenama | TIANMA |
| Saiz | 8.0 |
| Permohonan | Industrial |
| Resolusi | 1024×768 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K/16.7M |
| Lampu latar | 3S9P |
| Antara muka | |
| pengilang | TIANMA |
| saiz skrin | 8.0 inch |
| nombor piksel | 1024(RGB)×768 (XGA) 160PPI |
| kawasan aktif (mm) | 162.048 × 121.536 (H×V) |
| kawasan bezel (mm) | 164.65 × 124.14 (H×V) |
| kecerahan | 400 (Typ.)(cd/m²) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| pandangan yang baik di | 12 o'clock |
| kedalaman warna | 262K/16.7M 50% NTSC |
| jisim | 189g |
| kadar segar semula | 60Hz |
| nama model | TM080TDHG01-42 |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 183 × 141 × 3.7 (H×V×D) |
| rawatan | Clear |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| mod kerja | TN, Normally White, Transmissive |
| tindak balas | 20 (Typ.)(Tr+Td) ms |
| lampu latar | 3S9P WLED , 30K hours , No Driver |
| digunakan untuk | Industrial |
| skrin sentuh | Without |
