| Nombor Bahagian | TM070RDHG12 |
| Jenama | TIANMA |
| Saiz | 7.0 |
| Permohonan | Portable DVD Player |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama | TIANMA |
| model | TM070RDHG12 |
| saiz pepenjuru | 7.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 800(RGB)×480 [WVGA] 134PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 154.08(H)×85.92(V) mm |
| garis besar malap. | 164.9(H)×100(V) ×6(D) mm |
| kawasan bezel | 157.08(H)×89.39(V) mm |
| rawatan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) (TM) |
| arah pandang | 12 o'clock |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| sudut pandangan | 70/70/60/70 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K/16.7M 50% NTSC |
| sumber cahaya | WLED [3S7P] , 20K hours , W/O Driver |
| berat badan | 165g (Typ.) |
| direka untuk | Portable DVD Player Digital Photo Frame |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | Parallel RGB (1 ch, 6/8-bit) , 60 pins FPC |
| bekalan kuasa | 3.3/10.6/10.6/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
