| Nombor Bahagian | TM035WBHG01 |
| Jenama | Tianma |
| Saiz | 3.5 |
| Permohonan | HHP |
| Resolusi | 480×640 |
| Komposisi | LCM |
| Kecerahan | 250 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | TIANMA |
| model panel | TM035WBHG01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 3.5 inch |
| resolusi | 480(RGB)×640 , VGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 53.28×71.04 mm |
| garis besar | 64×85×4.63 mm |
| permukaan | Antiglare |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193150% |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 60/70/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 6S1PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 60 pins |
| voltan masukan | 2.8V (Typ.) |
| permohonan | HHP |
