| Nombor Bahagian | TD070WGCB1 |
| Jenama | TPO |
| Saiz | 7.0 |
| Permohonan | CNS |
| Resolusi | 854×480 |
| Komposisi | LCM |
| Kecerahan | 420 |
| CR | 150:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | TTL |
| jenama panel | Toppoly |
| model panel | TD070WGCB1 |
| jenis panel | LTPS TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 854(RGB)×480 , FWVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 155×87.12 mm |
| garis besar | 166.4×106.3×8.9 mm |
| permukaan | |
| kecerahan | 420 cd/m² (Typ.) |
| nisbah kontras | 150:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 7/18 (Typ.)(Tr/Td) |
| sudut pandangan | 75/75/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit), 40 pins |
| voltan masukan | 3.3V (Typ.)(VDD) |
| permohonan | CNS |
