| Nombor Bahagian | TD035SHED1 |
| Jenama | TPO |
| Saiz | 3.5 |
| Permohonan | MPH |
| Resolusi | 480×640 |
| Komposisi | LCM |
| Kecerahan | 170 |
| CR | 200:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | TPO |
| model panel | TD035SHED1 |
| jenis panel | LTPS TFT-LCD , LCM |
| saiz panel | 3.5 inch |
| resolusi | 480(RGB)×640 , VGA |
| mod paparan | TN, Normally White, Transflective |
| kawasan aktif | 53.28×71.04 mm |
| garis besar | 64×85 mm |
| permukaan | |
| kecerahan | 170 cd/m² (Typ.) |
| nisbah kontras | 200:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| warna paparan | 262K (6-bit), CIE193137% |
| masa tindak balas | 35 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 6S1PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit) + SPI, 51 pins |
| voltan masukan | 3.0/3.0V (Typ.)(VDC/VDDIO) |
| permohonan | MPH |
