| Nombor Bahagian | H466TAN01.1 |
| Jenama | AUO |
| Saiz | 4.7 |
| Permohonan | MPH |
| Resolusi | 720×1280 |
| Komposisi | CELL |
| Kecerahan | 0 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | No B/L |
| Antara muka | |
| jenama panel | AUO |
| model panel | H466TAN01.1 |
| jenis panel | LTPS TFT-LCD , CELL |
| saiz panel | 4.7 inch |
| resolusi | 720(RGB)×1280 , WXGA |
| mod paparan | AHVA, Normally Black, Transmissive |
| kawasan aktif | 58.104×103.296 mm |
| garis besar | 60.9×111.87 mm |
| permukaan | Hard coating |
| kedalaman kaca | 0.17+0.17 mm |
| ketransmisian | 3.9% (Typ.)(with Polarizer) |
| nisbah kontras | 1000:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193166% |
| masa tindak balas | 35 (Max.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| ic pemandu | COG Built-in NT35590 |
| permohonan | MPH |
| AMS300FW01-0 | Samsung | 3.0 | 240×400 |
| BV055FHM-N00 | BOE | 5.5 | 1080×1920 |
| LH350H02-FD02 | LG Display | 3.5 | 320×480 |
| LH500WF3-SH01 | LG Display | 5.0 | 1080×1920 |
| LH550WF1-SD01 | LG Display | 5.5 | 1080×1920 |
| LS020B8UD02 | SHARP | 2.0 | 176×220 |
| TD028STEB2 | TPO | 2.8 | 240×320 |
| TD035STEB1 | TPO | 3.5 | 240×320 |
| TM024HDH36 | Tianma | 2.4 | 240×320 |
| TM032PDZ13 | Tianma | 3.2 | 320×480 |
