| Nombor Bahagian | TCG121XGLPAPNN-AN20-S |
| Jenama | Kyocera |
| Saiz | 12.1 |
| Permohonan | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 750:1 |
| Warna | 262K/16.2M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | Kyocera |
| model | TCG121XGLPAPNN-AN20-S |
| saiz pepenjuru | 12.1 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×768 [XGA] 105PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 245.76(H)×184.32(V) mm |
| garis besar malap. | 260.5(H)×203.4(V) ×10.8(D) mm |
| kawasan bezel | 249.0(H)×187.5(V) mm |
| rawatan | Antiglare |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 750:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 18/12 (Typ.)(Tr/Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | AWV, Normally Black, Transmissive |
| warna sokongan | 262K/16.2M 50% NTSC |
| sumber cahaya | WLED , 50K hours , With LED Driver |
| berat badan | 670g |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
