| Nombor Bahagian | LMG9980ZWCC-01 |
| Jenama | KOE |
| Saiz | 12.1 |
| Permohonan | IA |
| Resolusi | 800×600 |
| Komposisi | LCM |
| Kecerahan | 70 |
| CR | 30:1 |
| Warna | Color |
| Lampu latar | CCFL |
| Antara muka | Parallel Data |
| jenama panel | HITACHI |
| model panel | LMG9980ZWCC-01 |
| jenis panel | CSTN-LCD , LCM |
| saiz panel | 12.1 inch |
| resolusi | 800(RGB)×600 , SVGA |
| mod paparan | STN, Normally Black |
| kawasan aktif | 246×184.5 mm |
| garis besar | 275×202.5 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 70 cd/m² (Typ.) |
| nisbah kontras | 30 : 1 (Typ.) |
| warna paparan | Color |
| masa tindak balas | 170/130 (Typ.)(Tr/Td) |
| sudut pandangan | 40 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| kekerapan | 120Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel Data (8-bit), 41 pins |
| voltan masukan | 3.3/5.0V (Typ.)(VDD) |
| permohonan | IA |
