| Nombor Bahagian | TCG085WVLCF-G00 |
| Jenama | Kyocera |
| Saiz | 8.5 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | Parallel |
| pengilang | Kyocera |
| nama model | TCG085WVLCF-G00 |
| saiz skrin | 8.5 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 800(RGB)×480 (WVGA) 109PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 184.8 × 110.88 (H×V) |
| garis besar (mm) | 210 × 134 × 11.1 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Antiglare |
| kecerahan | 320 cd/m² (Typ.) |
| nisbah kontras | 500 : 1 (Typ.) (TM) |
| sudut pandangan | 60/60/60/45 (Typ.)(CR≥10) |
| tindak balas | 15/35 (Typ.)(Tr/Td) ms |
| pandangan yang baik di | - |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K 49% NTSC |
| lampu latar | WLED , 50K hours , No Driver |
| jisim | TBD |
| digunakan untuk | Industrial |
| kadar segar semula | 60Hz |
| skrin sentuh | 4-wire Resistive Touch, G/G |
| jenis isyarat | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| A085FW01 V5 | AUO | 8.5 | 480×234 |
| G085VW01 V0 | AUO | 8.5 | 800×480 |
| G085VW01 V1 | AUO | 8.5 | 800×480 |
| G085VW01 V3 | AUO | 8.5 | 800×480 |
| KMT085WV | Samsung | 8.5 | 800×480 |
| LM085YB1T01 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG01 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG18 | SHARP | 8.5 | 800×480 |
| LT085AC18N00 | TOSHIBA | 8.5 | 800×480 |
| LW850AT9301 | Innolux | 8.5 | 800×480 |
